25 mm (1") High-End Silk dome driver with Magnetically shielded for the highrange above 2000 Hz.
File name：HiFi units / File size:2.47MB
| Noes: |
|
|
|
| cone |
|
: | trested silk dome |
| front |
|
: | ABS |
| voice coil |
|
: | NSV |
| magnet |
|
: | neodym N 35 |
| Terminals: |
|
|
|
| "+" 4.8 x 0.8 mm |
|
|
|
| "-" 2.8 x 0.8 mm |
|
|
|
| Technical data (EN): |
|
|
|
| nom impedance | (Ohm) | : | 8 |
| nom.power | (Watts) | : | 20 |
| peak SPL | (dB) | : | 93 |
| Sensitivity | (dB) | : | 91 |
| average SPL | (dB) | : | 89 |
| res.frequency | (Hz) | : | 760 |
| freq.Range (-10dB) | (Hz) | : | Fo to 20000 |
| Xmax +/- | (mm) | : | 0.8 |
| total weight | (kg) | : | 0.083 |
| voice coil ¢ | (mm) | : | 25 |
| power with 2.2 mF /100V |
|
|
|
| Thiele / Small parameter: |
|
|
|
| Re | (Ohm) | : | 7.1 |
| Qms |
|
: | 3.98 |
| Qes |
|
: | 1.71 |
| Qts |
|
: | 1.2 |
